Low loader semi-trailer

Goldhofer 6-Achs-Tele-Semi mit hydr.Rampen-zwangs.

Gooseneck, rigid, in central beam design:
- Loading area: 3,700 mm x 2,480 mm
- Angled at 10°, front corners at 45° (1,080 mm long, 190 mm high bevel at the gooseneck end)
- Closed outer frame
- Max. fifth wheel load: 26,000 kg
- Clearance radius: 2,700 mm
- 2" kingpin
- Wooden floor
- Hydraulically operated landing legs
- 1-piece aluminium sideboards, 400 mm high, closed on 3 sides incl. rear board, stanchions foldable and removable
- 2 pairs of lashing points LC 8,000 daN

Loading area:
- Simple telescopic extension, continuous over the running gear
- External/internal tube construction with 1,090 mm fixed loading platform at the front
- (L x W) 8,700 mm x 2,550 mm, extendable by 6,700 mm to a max. of 15,400 mm
- Steel plate flooring
- Locking of extension stages by spring-applied cylinder and tapered pin
- Vehicle optimized for maximum extension
- 7 pairs of lashing points LC 13,000 daN
Ledpfx Ajxp U Tzobljah
- 6 pairs of lashing points LC 6,000 daN
- 6 pairs of stanchion pockets 100 x 50 mm (LC 2,000 daN)

6-axle running gear:
- 1 rigid axle, 5 forced-steered axles
- Axle brand SAF
- Track width: 2,550 mm
- 1st axle: load-dependent lift axle
- 2nd axle: manually liftable (not load-dependent)
- Wheelbase, starting from first axle: 1,310 mm
- Twin tires 245/70 R 17.5
- Air suspension, 200 mm lift
- Ride height: 885 mm +100 mm / -100 mm
- 2nd ride height: 845 mm +140 mm / -60 mm
- Floor covering: steel/wood

Rear of vehicle:
- Design: "Bevelled" (600 mm long, 10° bevel)
- 1,000 mm rear overhang from center of last axle
- Detachable ramp eye on rear crossmember
- Mechanical support for stabilisation during loading
- 1 pair of lashing points LC 6,000 daN
- 1 pair of lashing points LC 13,000 daN

Ramps:
- Two-piece access ramps with lengths of 2,850 mm + 1,540 mm, width 720 mm
- Hydraulic ramp lifting device
- SuperGrip rubber flooring
- Climbing strips on outer side of ramps 20 mm x 20 mm x 100 mm
- Laterally adjustable by hydraulic cylinder to a maximum outer width of 2,790 mm or minimum inner spacing of 480 mm
- Integrated mechanical locking system in ramp lift cylinder for ramp safety during transport
- Mount for warning beacon

Hydraulics:
- Hydraulic connection for tractor unit (1 set), connections for tractor, hydraulic pump in tractor unit with max. 60 l/min flow
- Hydraulic emergency hand pump
- Electro-hydraulic power pack

Trailing steering:
- Trailing steering bottle for manual steering of trailer axles via cable remote control, spiral cable extendable from 1.5 m to 5 m

Accessories included:
- Spare wheel holder at the front of the gooseneck, plug-in type, galvanized
- Stanchion holder on the gooseneck
- 2 pairs warning signs, approx. 423 mm x 423 mm
- Widening including extension boards, attachable extension at vehicle rear
- 1 pair wheel chocks with holder
- 1 spare wheel
- Central lubrication system with 2 lubrication pumps
- Single-color paint finish, RAL-1001 Beige
