Low loader semitrailer

DOLL T2H Forst Teleskop 5,7M *Funk|Rampen|2xLenkachse

Loading with forklift possible for an additional charge and by prior arrangement. Please speak to the seller.

---General Vehicle Data---
Manufacturer: DOLL
* Type: 2-axle low-bed trailer
* Version: Low-bed, hydraulically forced steering
* Axles: 2 steered axles
* First registration: 09/2005
* Condition: Used vehicle
* Extras: Radio remote control, drive-on ramps

---Weights & Loads---
Permissible total weight: 41,000 kg
* Fifth wheel load: 21,000 kg
* Axle loads: 2 × 10,000 kg (total 20,000 kg)
* Unladen weight: approx. 13,700 kg (manufacturer's tolerance)
* Payload: approx. 27,300 kg

---Dimensions---
Total length: approx. 13,110 mm
* Overall width: approx. 2,550 mm
* Loading bed width: approx. 2,550 mm
* Neck width: approx. 2,480 mm
* Chassis width: approx. 2,550 mm
* Loading area length: approx. 6,700 mm
* Chassis length: approx. 2,800 mm
* Coupling height (laden): approx. 1,240 mm
* Loading height (max. laden): approx. 300 mm
* Axle spacing: approx. 1,360 mm
* B-measurement: approx. 12,000 mm

---Telescoping & Widening---
Technical telescoping extension: approx. 5,700 mm
* Telescoping intervals: each approx. 500 mm + container positions
* Widenings: up to approx. 3,000 mm
* Note: last telescoping stage permitted only in conjunction with container transport

---Chassis & Axles---
Axles: BPW, 17.5", 2 × 12 t
* Brakes: drum brakes, ABS, RSS
* Air suspension: electronic, approx. 260 mm lift
* Tires: 245/70 R 17.5 (8x, Continental HTL2)
* Rims: Steel rims 17.5 × 6.75

---Steering---
Hydraulic forced steering per ECE-R79
* Dual-circuit displacement steering
* Steering pick-up at fifth wheel
* Manometer for monitoring steering pressure
* Auxiliary steering: electro-hydraulic unit
* EEG electronic wheel alignment for straight-ahead driving

---Gooseneck---
Hydraulically removable gooseneck
* External main frame
* Integrated push-off cylinders
* Lifting and setting down of the low-bed
* Ladder with handrail
* King pin 2"

---Loading Area / Low-bed---
Flatbed design, extendable
* Wooden floor approx. 45 mm spruce
* Preloaded chassis frame for maximum payload
* Drivable chassis platform with excavator trough
* Max. wheel load over axles: approx. 8,000 kg
Hjdpfx Aeycpg Rjffjh

---Load Securing---
Low-bed:
* 7 pairs of swiveling lashing rings (each approx. 13,400 daN)
* Stake pockets 100 × 50 mm
* M36 thread for lashing brackets
Gooseneck:
* Lashing points up to approx. 13,400 daN
Chassis platform:
* Lashing rings and stake pockets integrated

---Hydraulics & Controls---
DOLL tronic CAN-Bus system
* Control panels (keypads) at gooseneck and rear
* Controls for:
* Steering
* Wheel alignment
* Ride height
* Central lubrication
* LED indicator for ride levels

---Central Lubrication---
BekaMax progressive central lubrication system
* Separate pumps for front and rear sections
* Automatic control via DOLL tronic

---Braking System---
Electronic air brake system (WABCO EBS-E)
* ABS, RSS
* Spring-loaded parking brake
* Aluminum air tank

---Electrics---
Sockets for oversize and overlength
* LED beacon
* 15-pin, 7-pin, 10-pin sockets

---German Trailer / Internal No: kk559---
* First registration: 09/2005
* Second owner

---Tires---
Axle 1: 235/75 R17.5 (approx. 50%)
* Axle 2: 235/75 R17.5 (approx. 50%)
