Standard SZMVolvo
FH 540 6x4
Standard SZM
Volvo
FH 540 6x4
ONO plus VAT
€41,500
(€49,385 gross)
Year of construction
2017
Condition
Used
Location
Bremen

Show images
Show map
Basic data
- Description:
- Standard SZM
- Manufacturer:
- Volvo
- Model:
- FH 540 6x4
- Year of construction:
- 2017
- Condition:
- used
- Functionality:
- fully functional
Price & Location
ONO plus VAT
€41,500
(€49,385 gross)
- Location:
- 28359 Bremen, Deutschland

Call
Technical details
- Mileage:
- 605,636 km
- Power:
- 405 kW (550.65 HP)
- First registration:
- 12/2017
- Fuel type:
- diesel
- Empty load weight:
- 10,516 kg
- Axle configuration:
- 6x4
- Fuel:
- diesel
Details about the offer
- Listing ID:
- A194-25-001
- Update:
- 09.04.2026
Description
Volvo FH 540 6x4 Tractor Unit CHH-STD, Air Suspension
Main Components
Globetrotter safety cab, FH
Wheelbase 3200 mm
Emission standard Euro 6 with SCR, particulate filter, and exhaust gas recirculation. Euro 6 C emissions.
Diesel engine D13, 551 hp / 405 kW, 2652 Nm
Engine brake exhaust pressure regulator (incl. engine management for I-Shift)
Iajdpfx Aaowu H Dle Hsr
I-Shift AT2612F, automated 12-speed gearbox, max input torque: 2,600 Nm
No liftable drive axle
Drive axle RTH2610F. Double axle hub reduction. Longitudinal and transverse differential locks. Axle ratio 3.33:1
Chassis
2-leaf parabolic suspension front
Front axle load max. 8.0 t (technical)
Front stabilizer, medium stiff
Rear axle load max. 26 t (technical)
Rear stabilizer reinforced
Axle load limiter 11.5 t
Steering pump with fixed flow
Disc brakes, solid discs
EBS, electronic braking system, medium package
Additional spring accumulator, front axle (or 2nd drive axle on 6x4)
Frame profile height 300 mm
Frame thickness 8.0 mm
Inner frame from gearbox cross member to behind axle suspension, cover for compressed air components on chassis
Battery box at the rear overhang
2 batteries, 24V/225 Ah. CCA DIN/SAE 690/1150 A
Standard batteries
Battery display in dashboard (voltage, current and battery status with warning function). Battery pulse device
Main switch on chassis
No tank on right, main tank on left
700 L aluminium tank left, D710, entry steps
AdBlue tank usable volume 100 litres
Cover for AdBlue tank, silver metallic paint
Lockable tank cap
Tank filling nozzle with anti-spill protection
Exhaust outlet to rear
2 folding wheel chocks
Rear frame length 2365 mm, measured from drive axle/1st drive axle
One towing device, front
Electrical connection for semi-trailer/trailer, 2 x 7-pin (UADR)
Trailer/semitrailer connection EC standard
Retaining bracket (steel) for trailer connections behind cab
Stationary trailer brake (active up to 7 km/h)
Aluminium air tanks
Brake lights with emergency braking flash sequence
Wheels and Tires
Front axle tires 385/55 R22.5
Drive axle tires 315/70 R22.5
Driveline Equipment
Reverse gear function for crawler gears
Crawler gears, slow & very slow
Mechanical vent pump
Onboard diagnostics: Euro 6, Stage C
Automated gear shift, selector lever on seat
Heavy duty program for weights over 60 t (FH) or 85 t (FH16)
Off-road auxiliary program
Extended PTO functions for I-Shift
Servo-assisted single-plate dry clutch, diameter 430 mm
Transmission output torque: high load (HD)
Compact retarder, gearbox-mounted (rear), for I-Shift and manual gearboxes
Gearbox oil cooler, high performance, air/oil
Air compressor 2-cylinder, 1100 l/min, for vehicles/combinations with increased air demand. Air compressor without clutch
Alternator 150A/4200W
Noise dampening to 80 dB(A) according to RL 92/97 EEC (EU-96)
Closed crankcase ventilation down to -25°C, closed system
Reinforced gearbox
Dual fuel filter on engine, standard size
PTO (medium speed), gearbox side, connection:
1 DIN rear for pump (max. 600 Nm). PTO on gearbox, output max. 600 Nm
The listing was translated automatically. Translation errors are possible.
Main Components
Globetrotter safety cab, FH
Wheelbase 3200 mm
Emission standard Euro 6 with SCR, particulate filter, and exhaust gas recirculation. Euro 6 C emissions.
Diesel engine D13, 551 hp / 405 kW, 2652 Nm
Engine brake exhaust pressure regulator (incl. engine management for I-Shift)
Iajdpfx Aaowu H Dle Hsr
I-Shift AT2612F, automated 12-speed gearbox, max input torque: 2,600 Nm
No liftable drive axle
Drive axle RTH2610F. Double axle hub reduction. Longitudinal and transverse differential locks. Axle ratio 3.33:1
Chassis
2-leaf parabolic suspension front
Front axle load max. 8.0 t (technical)
Front stabilizer, medium stiff
Rear axle load max. 26 t (technical)
Rear stabilizer reinforced
Axle load limiter 11.5 t
Steering pump with fixed flow
Disc brakes, solid discs
EBS, electronic braking system, medium package
Additional spring accumulator, front axle (or 2nd drive axle on 6x4)
Frame profile height 300 mm
Frame thickness 8.0 mm
Inner frame from gearbox cross member to behind axle suspension, cover for compressed air components on chassis
Battery box at the rear overhang
2 batteries, 24V/225 Ah. CCA DIN/SAE 690/1150 A
Standard batteries
Battery display in dashboard (voltage, current and battery status with warning function). Battery pulse device
Main switch on chassis
No tank on right, main tank on left
700 L aluminium tank left, D710, entry steps
AdBlue tank usable volume 100 litres
Cover for AdBlue tank, silver metallic paint
Lockable tank cap
Tank filling nozzle with anti-spill protection
Exhaust outlet to rear
2 folding wheel chocks
Rear frame length 2365 mm, measured from drive axle/1st drive axle
One towing device, front
Electrical connection for semi-trailer/trailer, 2 x 7-pin (UADR)
Trailer/semitrailer connection EC standard
Retaining bracket (steel) for trailer connections behind cab
Stationary trailer brake (active up to 7 km/h)
Aluminium air tanks
Brake lights with emergency braking flash sequence
Wheels and Tires
Front axle tires 385/55 R22.5
Drive axle tires 315/70 R22.5
Driveline Equipment
Reverse gear function for crawler gears
Crawler gears, slow & very slow
Mechanical vent pump
Onboard diagnostics: Euro 6, Stage C
Automated gear shift, selector lever on seat
Heavy duty program for weights over 60 t (FH) or 85 t (FH16)
Off-road auxiliary program
Extended PTO functions for I-Shift
Servo-assisted single-plate dry clutch, diameter 430 mm
Transmission output torque: high load (HD)
Compact retarder, gearbox-mounted (rear), for I-Shift and manual gearboxes
Gearbox oil cooler, high performance, air/oil
Air compressor 2-cylinder, 1100 l/min, for vehicles/combinations with increased air demand. Air compressor without clutch
Alternator 150A/4200W
Noise dampening to 80 dB(A) according to RL 92/97 EEC (EU-96)
Closed crankcase ventilation down to -25°C, closed system
Reinforced gearbox
Dual fuel filter on engine, standard size
PTO (medium speed), gearbox side, connection:
1 DIN rear for pump (max. 600 Nm). PTO on gearbox, output max. 600 Nm
The listing was translated automatically. Translation errors are possible.
